Essentials

    Product Collection 7th Generation Intel® Core™ i5 Processors
    Code Name Products formerly Kaby Lake
    Vertical Segment Desktop
    Processor Number i5-7400
    Status Launched
    Launch Date Q1'17
    Lithography 14 nm

Performance

    # of Cores 4
    # of Threads 4
    Processor Base Frequency 3.00 GHz
    Max Turbo Frequency 3.50 GHz
    Cache 6 MB SmartCache
    Bus Speed 8 GT/s DMI3
    # of QPI Links 0
    TDP 65 W

Supplemental Information

    Embedded Options Available No
    Conflict Free Yes
    Datasheet View now

Learn how Intel is pursuing conflict-free technology.
Memory Specifications

    Max Memory Size (dependent on memory type) 64 GB
    Memory Types DDR4-2133/2400, DDR3L-1333/1600 @ 1.35V
    Max # of Memory Channels 2
    ECC Memory Supported ‡ No

Graphics Specifications

    Processor Graphics ‡ Intel® HD Graphics 630
    Graphics Base Frequency 350.00 MHz
    Graphics Max Dynamic Frequency 1.00 GHz
    Graphics Video Max Memory 64 GB
    4K Support Yes, at 60Hz
    Max Resolution (HDMI 1.4)‡ 4096x2304@24Hz
    Max Resolution (DP)‡ 4096x2304@60Hz
    Max Resolution (eDP - Integrated Flat Panel)‡ 4096x2304@60Hz
    DirectX* Support 12
    OpenGL* Support 4.4
    Intel® Quick Sync Video Yes
    Intel® InTru™ 3D Technology Yes
    Intel® Clear Video HD Technology Yes
    Intel® Clear Video Technology Yes
    # of Displays Supported ‡ 3
    Device ID 0x5912

Expansion Options

    Scalability 1S Only
    PCI Express Revision 3.0
    PCI Express Configurations ‡ Up to 1x16, 2x8, 1x8+2x4
    Max # of PCI Express Lanes 16

Package Specifications

    Sockets Supported FCLGA1151
    Max CPU Configuration 1
    Thermal Solution Specification PCG 2015C (65W)
    TJUNCTION 100°C
    Package Size 37.5mm x 37.5mm
    Low Halogen Options Available See MDDS

Advanced Technologies

    Intel® Optane™ Memory Supported ‡ Yes
    Intel® Turbo Boost Technology ‡ 2.0
    Intel® vPro™ Technology ‡ No
    Intel® Virtualization Technology (VT-x) ‡ Yes
    Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
    Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
    Intel® TSX-NI Yes
    Intel® 64 ‡ Yes
    Instruction Set 64-bit
    Instruction Set Extensions SSE4.1/4.2, AVX 2.0
    Idle States Yes
    Enhanced Intel SpeedStep® Technology Yes
    Thermal Monitoring Technologies Yes
    Intel® Identity Protection Technology ‡ Yes
    Intel® Stable Image Platform Program (SIPP) No

Intel® Data Protection Technology

    Intel® AES New Instructions Yes
    Secure Key Yes
    Intel® Software Guard Extensions (Intel® SGX) Yes
    Intel® Memory Protection Extensions (Intel® MPX) Yes

Intel® Platform Protection Technology

    OS Guard Yes
    Execute Disable Bit ‡ Yes
    Intel® Device Protection Technology with Boot Guard Yes
